RK3288 LCD IPS 15.6 touch screen Android Tablet PC with LED Bar Light
- Model No.: MA1560-A
- 15.6 inch IPS panel, 1920x1080 FHD Res
- CPU: RK3288 / RK3566 / RK3568/ RK3399 for choice
- 10-point capacitive touchscreen
- Network: Wifi, RJ45, Bluetooth
- Interface: SD card, USB, RJ45
- Mounting type: 75x75mm VESA
- Warranty: 2-years since received monitors
- Specifications
| System | CPU | 1.Quad core cortex A17,1.6G,RK3288 2.RK3566 Quad core cortex A55 3.RK3568 Quad core cortex A55 4.Dual-core A72+quad-core A53,1.8G,RK3399 |
||||||||||||
| RAM | 2GB (4GB optional) | |||||||||||||
| Internal memory | 16GB (32GB / 64GB optional) | |||||||||||||
| Operation system | Android 8.1 / 10 / 11 | |||||||||||||
| Display | Screen | 15.6″ LCD IPS screen, LED backlight | ||||||||||||
| Resolution | 1920×1080 @60Hz | |||||||||||||
| Brightness | 350cd/m2 | |||||||||||||
| Contrast | 800:1 | |||||||||||||
| dot pitch | 0.297×0.297 | |||||||||||||
| Display area | 344.16(H)x193.59mm(V) | |||||||||||||
| Viewing angles | 89/89(H),89/89(V) | |||||||||||||
| Color | 16.7M | |||||||||||||
| Aspect Ratio | 16:9 | |||||||||||||
| Network | WiFi | RK3288: 802.11b/g/n RK3399: 802.11b/g/n/ac, 2.4G+5G |
||||||||||||
| Ethernet | RJ45 | |||||||||||||
| Bluetooth | Bluetooth 4.0 | |||||||||||||
| Interface | SD card slot | SD,Support up to 32GB | ||||||||||||
| USB Device | Mini USB OTG | |||||||||||||
| USB | 1xUSB for serial ; 1x USB Host | |||||||||||||
| RJ45 with POE | Ethernet | |||||||||||||
| POE | IEEE802.3at/af | |||||||||||||
| Power jack | DC power input | |||||||||||||
| Earphone | 3.5mm earphone + Micphone | |||||||||||||
| Multi-Media | Audio | MP3/WMA/AAC etc. | ||||||||||||
| Video | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4K | |||||||||||||
| Picture | JPEG | |||||||||||||
| Other functions | Working temp | 0–40degree | ||||||||||||
| NFC | Optional,NFC 13.56MHz，ISO14443A/ISO14443B/ISO 15693/Mifare classic/Sony felica | |||||||||||||
| LED Light bar | LED Light bar | |||||||||||||
| Speakers | Built-in 2×1.5W speakers | |||||||||||||
| Camera | 2.0M/P,Front camera | |||||||||||||
| VESA | 75x75mm | |||||||||||||
| Color | White/Black | |||||||||||||
| OSD language | Multi OSD language | |||||||||||||
| Accessories | Adapter | Adapter,12V,2A | ||||||||||||
| Wall Mount Bracket | One | |||||||||||||
| User manual | One | |||||||||||||
