Front NFC RFID Reader 10.1 inch PoE Android Tablet Touch Screen Panel
- Model No.: MA1001
- 10.1 inch IPS panel, 1280x800 HD Res
- CPU: RK3288 / RK3566 / RK3568/ RK3399 for choice
- 10-point capacitive touchscreen
- Network: Wifi, RJ45, Bluetooth
- Interface: SD card, USB, RJ45
- Mounting type: Wall Mount
- Option : POE , NFC
- Warranty: 2-years since received monitors
- Specifications
| System | CPU | 1.Quad core cortex A17,1.6G,RK3288 2.RK3566 Quad core cortex A55 3.RK3568 Quad core cortex A55 4.Dual-core A72+quad-core A53,1.8G,RK3399 |
||||||||||||
| RAM | 2GB (4GB optional) | |||||||||||||
| Internal memory | 16GB ( 32GB / 64GB Option ) | |||||||||||||
| Operation system | Android 8.1 / 10 / 11 | |||||||||||||
| Display | Screen | 10.1″ LCD IPS screen, LED backlight | ||||||||||||
| Resolution | 1280×800 @60Hz | |||||||||||||
| Brightness | 250cd/m2 | |||||||||||||
| Contrast | 800:1 | |||||||||||||
| dot pitch | 0.297×0.297 | |||||||||||||
| Viewing angles | 89/89(H),89/89(V) | |||||||||||||
| Color | 16.7M | |||||||||||||
| Aspect Ratio | 16:9 | |||||||||||||
| Network | WiFi | 802.11b/g/n | ||||||||||||
| Ethernet | RJ45 | |||||||||||||
| Bluetooth | Bluetooth 4.0 | |||||||||||||
| Interface | SD | 1×SD card slots (max support 32GB) | ||||||||||||
| USB | USB Host | |||||||||||||
| Micro USB | Micro USB OTG | |||||||||||||
| RJ45 with POE | Ethernet interface ;POE Option (MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 1080p) | |||||||||||||
| USB | USB for serial | |||||||||||||
| Power jack | DC power input | |||||||||||||
| Earphone | 3.5mm earphone + Micphone | |||||||||||||
| Multi-Media | Audio | MP3/WMA/AAC etc. | ||||||||||||
| Video | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4K | |||||||||||||
| Picture | JPEG | |||||||||||||
| Other functions | LED Light bar | LED Light bar | ||||||||||||
| Touch Screen | 10-Point capacitive touch | |||||||||||||
| OSD language | Multi OSD language | |||||||||||||
| Speakers | Built-in 2×1.5W speakers | |||||||||||||
| VESA | 75mm*75mm | |||||||||||||
| Camera | 2.0M/P,front camera | |||||||||||||
| Working temp | 0–50degree | |||||||||||||
| Color | White/Black | |||||||||||||
| Accessories | Adapter | Adapter,12V,2A | ||||||||||||
| User manual | One | |||||||||||||
