1000 nits 1440*900 Wide Screen 19″ Open Frame Touch Monitor
- Model : MO190W
- 1)Different sizes available;
- 2)IR/Capacitive touch screen;
- 3)Industrial A+ grade LCD panel;
- 4)Open frame design;
- 5)Intelligence temperature control fan design,green and quiet.
- 6)Wide visual angle 178 degree;
- 7)Rich signal input,output interfaces,adapted in the different environments.
- 8)Build-in stable power,low consumption,long life span>60000hours
- Specifications
| Specification | |||||
| General | |||||
| Series | Water-proof | ||||
| LCD Type | 19” TFT-LCD | ||||
| Video Input | VGA and HDMI | ||||
| OSD controls | Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | ||||
| Power Supply | Type: External brick | ||||
| Input (line) voltage: 100-240 VAC, 50-60 Hz | |||||
| Output voltage/current: 12 volts at 4 amps max | |||||
| Mount Interface | 1)VESA 75mm and 100mm | ||||
| 2)Mount bracket, horizontal or vertical | |||||
| LCD Specification | |||||
| Active Area(mm) | 410(H)×255(V) | ||||
| Resolution | 1440*900 | ||||
| Dot Pitch(mm) | 0.294×0.294 | ||||
| Nominal Input Voltage VDD | +5.0V(Typ) | ||||
| Viewing angle (v/h) | 80°/85° | ||||
| Contrast | 1000:1 | ||||
| Luminance(cd/m2) | 350,1000 nits | ||||
| Response Time(Rising) | 5ms/5ms | ||||
| Support Color | 16.7M colors | ||||
| Backlight MTBF(hr) | 30000 | ||||
| Touchscreen Specification | |||||
| Type | Projected Capacitive touch screen | ||||
| Resolution | 10points touch | ||||
| Touch Life Cycle | 10 millions | ||||
| Touch Response time | 5ms | ||||
| Touch System Interface | USB interface | ||||
| Power consumption | +5V@80mA | ||||
| External AC Power Adapter | |||||
| Output | DC 12V /4A | ||||
| Input | 100-240 VAC, 50-60 Hz | ||||
| MTBF | 50000 hr at 25°C | ||||
| Environment | |||||
| Operating Temp. | 0～50°C | ||||
| Storage Temp. | -20～60°C | ||||
| Operating RH: | 20%～80% | ||||
| Storage RH: | 10%～90% | ||||
| Components | |||||
| USB Cable 180cm*1 Pcs, | |||||
| VGA Cable 180cm*1 Pcs, | |||||
| Power Cord with Switching Adapter *1 Pcs, | |||||
| Bracket*8 Pcs | |||||
